Multifunctional&Single Phase Industrial Socket Supplier, Factory

SF-1012-4 IP44 110V 16A Two Way Multifunction Industrial Socket

Code:	SF-1012-4
Input:	110V 2P+E
Output:	16A 110V 2P+E
Protection degree:	IP44
Color:	Yellow

SF-1012 IP44 220V Y Type Multifunctional Industrial Socket

Code:	SF-1012
Input:	220V 2P+E
Output:	16A 220V 2P+E
Protection degree:	IP44
Color:	Blue

SF-1012/4 380V 16A 3P+E Multifunctional Industrial Socket

Code:	SF-1012/4
Input:	380V 3P+E
Output:	16A 380V 3P+E
Protection degree:	IP44
Color:	Red

SF-1013-4 110V 2P+E 3 Pins Extension Industrial Socket

Code:	SF-1013-4
Input:	110V 2P+E
Output:	16A 110V 2P+E
Protection degree:	IP44
Color:	Yellow

SF-1013 220V 16A 3 Pin Blue Multifunctional Industrial Socket

Code:	SF-1013
Input:	220V 2P+E
Output:	16A 220V 2P+E
Protection degree:	IP44
Color:	Blue

SF-1014 / 214 IP44 380V 3P+E Multifunctional Industrial Socket

Code:	SF-1014/214
Input:	380V 3P+E
Output:	16A 380V 3P+E
Protection degree:	IP44
Color:	Red

SFN-1013-4 110V 16A Single Phase Industrial Socket

Code:	SFN-1013-4
Input:	110V 2P+E
Output:	16A 110V 2P+E
Protection degree:	IP44
Color:	Yellow

SFN-1013 IP44 220V Multifunctional Industrial Socket

Code:	SFN-1013
Input:	220V 2P+E
Output:	16A 220V 2P+E
Protection degree:	IP44
Color:	Blue

SFN-10132-4 IP67 110V 16A Industrial Socket

Code:	SFN-10132-4
Input:	110V 2P+E
Output:	16A 110V 2P+E
Protection degree:	IP67
Color:	Yellow

SFN-10132 220V 16A 2P+E Industrial Socket

Code:	SFN-10132
Input:	220V 2P+E
Output:	16A 220V 2P+E
Protection degree:	IP67
Color:	Blue

SF-1023 IP44 220V 32A Multifunctional Industrial Socket

Code:	SF-1023
Input:	220V 2P+E
Output:	32A 220V 2P+E
Protection degree:	IP44
Color:	Blue

SF-1024 / 224 380V Single Phase Industrial Socket

Code:	SF-1024/224
Input:	380V 3P+E
Output:	32A 380V 3P+E
Protection degree:	IP44
Color:	Red

About

Wenzhou Shangfeng Electric Co.,Ltd.

Wenzhou Shangfeng Electric Co.,Ltd. is located in Liushi, the "Chinese Electrical Capital", adjacent to the Yongtaiwen Expressway and National Highway 104, the largest port in Wenzhou - Qili Port in the south, and the Wenzhou Airport and Railway Station in the west. The sea, land, and air transportation is very convenient.
As China Multifunctional Industrial Socket suppliers and Multifunctional Industrial Socket factory, we are mainly engaged in wholesale Multifunctional Industrial Socket, The company has introduced advanced technology and equipment, passed the ISO9001 international quality system, China Quality Certification Center CQC certification, and obtained the European Community CE safety certification, ROHS environmental protection directive certification, and continuously introduced senior technical personnel and enterprise management personnel, and has gradually acquired production technology. The company specializes in producing industrial plugs, sockets, couplers (connectors), nylon cable ties, and other products. The company strictly follows international standards such as IEC60309, EN60309, and CEE17 and national standards such as GB11918 and GB11919. The product design is unique and the structure is reasonable.

Certificate Of Honor

News

63A Industrial Plug Manufacturer: The Connector That Carries the Real Load
06 Nov, 2026
A 63A industrial plug is not the plug on a household extension cord. It runs the distribution boards, the stage lighting...
READ MORE
High-Performance 200A Industrial Power Plug: Demand Grows for Heavy-Duty Power Connections
30 Oct, 2026
High-performance 200A industrial power plugs are seeing demand from data centers, large manufacturing plants, and tempor...
READ MORE
Low-Voltage Rated Safety Industrial Plug: When 24 Volts Still Has to Be Treated Like It Can Hurt
23 Oct, 2026
The voltage is low. The current is not. A 24V control circuit can carry 16 amps or more, and a loose connection at that ...
READ MORE
63A Industrial Plug Factory: Demand Grows for High-Current Power Connections
16 Oct, 2026
63A industrial plug factories are seeing steady demand from construction sites, manufacturing plants, and temporary powe...
READ MORE

Multifunctional Industrial Sockets: How to Choose the Right Single-Phase Outlet for Safer Power Distribution

On industrial sites, the socket is rarely "just a socket." It's a decision point that affects downtime, maintenance speed, and operator safety. A well-chosen Multifunctional Industrial Socket can simplify power access across mixed equipment, while a properly specified Single Phase Industrial Socket keeps everyday loads stable and predictable.

What "Multifunctional" Really Means (and why it matters)

In practice, "multifunctional" usually refers to a socket solution that supports more than one real installation need, such as:

Practical layout flexibility (e.g., suited for panels, enclosures, or on-site distribution points)
A design that supports clean cable management and easier maintenance access
Configuration options that help standardize connections across tools and equipment
Construction intended for industrial environments (dust, splashes, impact risk, frequent plugging/unplugging)

The advantage is operational: you reduce the number of different outlets you must stock, maintain, and train people to use correctly—especially in facilities with rotating equipment and temporary setups.

Single-Phase Industrial Sockets: where they fit best

Single-phase power is common for many day-to-day loads, such as:

Portable tools and jobsite equipment
Small-to-mid machines and auxiliary devices
Maintenance bays and service areas
Temporary power points for contractors

A Single Phase Industrial Socket becomes "industrial-grade" when it's selected and installed to match the load profile, duty cycle, and environmental exposure—not just the plug shape.

Key Selection Checks (the ones engineers actually use)

When comparing industrial sockets, these checkpoints prevent most site problems:

1) Electrical rating alignment
- Confirm voltage/current/frequency requirements for the load
- Avoid "close enough" matching; small mismatches create heat and nuisance failures
2) Configuration + compatibility
- Choose the correct pin arrangement and wiring expectations (application-dependent)
- Standardize where possible to cut errors during shift changes
3) Environment and protection expectations
- For wet, dusty, or outdoor areas, protection level and enclosure quality matter
- For high-traffic areas, mechanical robustness reduces accidental breakage
4) Installation and maintenance reality
- Can a technician inspect wiring quickly?
- Is there space for safe cable routing and strain relief?
- Does the design reduce time-to-replace during a breakdown?
5) Safety and compliance mindset
- Use products and installation methods aligned with your market's norms (EU/UK/US)
- Documentation, traceability, and consistent labeling help during audits and servicing
